TP-502MHB MINI HORI - semi-automatic strapping machine
The machine works with polypropylene strap (PP). It has wide application, can be used for strapping of crates of fruit and vegetables, different kinds of panels, pallets of cardboard boxes, etc. . This is battery version of strapping machine TP-202MH.
Among main advantages of this strapping machine belong:
- speed
- ergonomic design
- economical working
- adjustable height of strapping from 190 to 2000 mm (from the floor)
- the control panel is on both sides of the machine - easy use and easy, comfortable and facilitating replacing of the strap
- big wheels for better moving
Cooling time can be extended for higher strenght of weld. This semi-automatic machine is suitable for low and medium frequency strapping jobs.
Technical parameters
Modification
Packing material
Inquiry
Technical parameters
| ordering code | 700 011930 |
| strap - material |
PP |
| strap width | 9 - 15,5 mm |
| inner diameter of roll | 200 mm |
| strap thickness | 0,6 - 0,8 mm |
| supply voltage | 230V/50Hz (12V) |
| packing rate | 4 straps/min. |
| tightening power | 80-700 N |
| min. size of wrapped object | 80 x 175 mm |
| battery charge time | 5-7 hod. hour |
| battery life – No. of charging cycles | 1000 |
| machine length | 1130 mm |
| machine width | 1131 mm |
| machine height | 2822 mm |
| weight | 344 kg |
Standard modifications
TP-502MH MINI HORI - semi-automatic strapping machine
- strap width - 9 - 15,5 mm
- adjustable strapping height
- quick, ergonomic and economic
- for low frequency jobs
Binding and packaging materials
PP strap 10 x 0,40 mm, 200/190 - 3500 m, 1160 N, black
- width 10 mm, thickness 0,40 mm
- black color
- strenght 1160 N
- tube 200 mm, roll 3500 m
PP strap 12 x 0,50 mm, 200/190 - 3100 m, 1300 N, black
- width 12 mm, thickness 0,50 mm
- black color
- strength 1300 N
- tube 200 mm, roll 3100 m
PP strap 15 x 0,65 mm, 200/190 - 2000 m, 2200 N, white
- width 15 mm, thickness 0,65 mm
- white, cross strapped
- strength 2200 N
- tube 200, roll 2000 m
PP strap 15 x 0,65 mm, 200/190 - 2000 m, 2200N, black
- width 15 mm, thickness 0,65 mm
- black color
- strength 2200 N
- tube 200, roll 2000 m
